Inputs
|
32Mbps ~96Mbps Decrease one Analog channel can increase 8Mbps Analog channel and digital channel can be converted
|
|
Out
|
96Mbps
|
|
Analog-Video-Input
|
8CH inputs
|
|
IP Video Input
|
4ch,(only IP up to 12ch)
|
|
Composite Video Input
|
Up to 12ch (Analog video + IP video)
|
|
Compression
|
G.711a Video
|
|
Display Resolution
|
8MP (15fps) 5MP (20fps) 4MP/1080P/720P/960H (30fps) IP
|
|
Speed
|
8MP
|
|
Event
|
MD (Sensitivity Level 1~8) Videlo loss Beep, Email, Push notification to Mobile APP
|
|
Playback Function
|
Fast forward / backward (2x, 4x, 8x,16x) Slow forward (1/2x, 1/4x, 1/8x,1/16x)
|
|
Playback
|
72fps (Max 8CH playback) 5MP
|
|
AI Features
|
PERIMETER INTRUSION DETECTION FACE DETECTION LINE CROSSING DETECTION STATIONARY OBJECT DETECTION* HUMAN & VEHICLE DETECTION CROWD DENSITY DETECTION* LICENSE PLATE DETECTION* RARE SOUND DETECTION* NOISE DETECTION* QUEUE LENGTH DETECTION* VIDEO TAMPERING* AI MAX CAPTURED QUANTITY 200,000 AI REGISTERED QUANTITY 10,000 *THESE AI FEATURES ONLY WORK WITH IP CAMERAS, OR ANALOG CAMERAS WITH 2MP OR MORE
|
|
Local
|
UI5.0
|
|
Web
|
IE10/11 Safari V12.1 above Firefox V.52 above Google chrome V.57 above Edge V.79 above
|
|
Mobile Viewer
|
SMART GUARDIAN
|
|
Push Notifications
|
Yes
|
|
P/W Reset
|
Press 10 seconds
|
|
BNC
|
1 (704*576)
|
|
VGA
|
1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080)
|
|
HDMI
|
1(1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 2560*1440, 3840*2160/EDID)
|
|
Ethernet
|
1 RJ45 100/1000 Base-T
|
|
USB
|
USB2.0*1(front) USB3.0*1+(rear)
|
|
Audio
|
8 in /1 out
|
|
HDD
|
1 SATA HDD, up to 16TB
|
|
RS485
|
1
|
|
Alarm Input/Out
|
8 in /1 out
|
|
OSD Language
|
EN/FR/ES/DN/TC/IN/JP/KR
|
|
Dimension (WXHXD)
|
300X220X53mm
|
|
Input Voltage / Current
|
DC12V/2A
|
|
Power Consumption (Excluding Hard Disk)
|
11W
|
|
Operating Temperature/Humidity
|
-10°C~+50°C (14°F ~ 122°F) Humidity
|
|
Hard Drive PURPLE
|
NO PURPLE HDD
,
2TB
,
4TB
,
8TB
|
8MP RESOLUTION
