| AI Features |
PERIMETER INTRUSION DETECTION FACE DETECTION LINE CROSSING DETECTION STATIONARY OBJECT DETECTION* HUMAN & VEHICLE DETECTION CROWD DENSITY DETECTION* LICENSE PLATE DETECTION* RARE SOUND DETECTION* NOISE DETECTION* QUEUE LENGTH DETECTION* VIDEO TAMPERING* AI MAX CAPTURED QUANTITY 200,000 AI REGISTERED QUANTITY 10,000 *THESE AI FEATURES ONLY WORK WITH IP CAMERAS, OR ANALOG CAMERAS WITH 2MP OR MORE
|
| Audio |
8 in /1 out
|
|
| Web |
IE10/11 Safari V12.1 above Firefox V.52 above Google chrome V.57 above Edge V.79 above
|
| Ethernet |
1 RJ45 100/1000 Base-T
|
|
| OSD Language |
EN/FR/ES/DN/TC/IN/JP/KR
|
| Dimension (WXHXD) |
300X220X53mm
|
| Input Voltage / Current |
DC12V/2A
|
| Power Consumption (Excluding Hard Disk) |
11W
|
| Operating Temperature/Humidity |
-10°C~+50°C (14°F ~ 122°F) Humidity
|
|
| Hard Drive PURPLE |
NO PURPLE HDD
,
2TB
,
4TB
,
8TB
|
|
| P/W Reset |
Press 10 seconds
|
| VGA |
1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080)
|
| HDMI |
1(1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 2560*1440, 3840*2160/EDID)
|
|
| Inputs |
32Mbps ~96Mbps Decrease one Analog channel can increase 8Mbps Analog channel and digital channel can be converted
|
| Out |
96Mbps
|
| Analog-Video-Input |
8CH inputs
|
|
| Compression |
G.711a Video
|
| Display Resolution |
8MP (15fps) 5MP (20fps) 4MP/1080P/720P/960H (30fps) IP
|
| Speed |
8MP
|
| Event |
MD (Sensitivity Level 1~8) Videlo loss Beep, Email, Push notification to Mobile APP
|
| Playback Function |
Fast forward / backward (2x, 4x, 8x,16x) Slow forward (1/2x, 1/4x, 1/8x,1/16x)
|
| Playback |
72fps (Max 8CH playback) 5MP
|
|
| Local |
UI5.0
|
| Mobile Viewer |
SMART GUARDIAN
|
| Push Notifications |
Yes
|
| BNC |
1 (704*576)
|
|
| USB |
USB2.0*1(front) USB3.0*1+(rear)
|
| HDD |
1 SATA HDD, up to 16TB
|
| RS485 |
1
|
| Alarm Input/Out |
8 in /1 out
|
|
| IP Video Input |
4ch,(only IP up to 12ch)
|
| Composite Video Input |
Up to 12ch (Analog video + IP video)
|
|
8MP RESOLUTION
