| IR LED |
2
|
| Warmlight |
2
|
| Red & Blue Light |
2 (1 Red & 1 Blue)
|
| IR Viewable Length |
Up to 45m
|
| Warmlight Viewable Length |
Up to 25m
|
| Type Of Complementary Light |
Default warm light, switchable infrared light
|
| Motion Detection |
Off/On (8 Levels)
|
| Wide Dynamic Range |
WDR
|
| Digital Noise Reduction |
3D DNR
|
| Image Setting |
Day&Night Mode/Full Color Mode/Schedule
|
| White Balance |
Auto/Manual
|
| Electronic Shutter Speed |
1/5 ~ 1/20000s
|
| On-Board Storage |
Micro SD slot, up to 256GB
|
| Alarm |
1 input, 1 output
|
| Audio |
Built-in microphone & Speaker; 1 input (RCA), 1 output (RCA)
|
| Custom Voice |
Yes
|
| Hardware Reset |
Yes
|
| Smart Features |
Rare Sound Detection (SD) , Perimeter Intrusion Detection (PID), Face Detection (FD), Stationary Object Detection (SOD), Crowd Density Detection (CD), Human&Vehicle Detection (PD&VD), Line Crossing Detection (LCD), Queue Lenght Detection (QD), Heat Map (HM), Cross Counting (CC), License Plate Detection (LPD)
|
|
| Ethernet |
RJ45(10/100BASE-T)
|
| Video Compression Format |
H.265/H.264
|
| Resolution |
Mainstream @30fps 5MP(2880x1620), 4MP(2560X1440) 3MP(2304x1296), 1080P(1920x1080), 720P(1280x720) Substream @30fps 720P(1280x720),VGA(640x480),QVGA(320x240) Mobile Stream @30fps VGA (640x480), QVGA (320x240)
|
| Video Quality Adjustment |
256Kbps ~ 8Mbps
|
| Bitrate Control Method |
CBR/VBR
|
| IP |
IPv6
|
| Protocol |
TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
|
| Security |
IP address filter;complicated password; Authenticated username and password
|
| Application Programming Interface |
ONVIF( Profile S/G/T)
|
| Web Viewer |
IE10/11, Safari V12.1 above, Firefox V.52 above Google chrome V.57 above, Edge V.79 above
|
|
| Operating Conditions |
-35 ~ +60°C/less than ≤ 95% RH
|
| Ingress Protection |
IP67
|
| Input Voltage / Current |
D12V/POE(IEEE802.3af)
|
| Power Consumption |
max 5.7W; POE (48V)
|
| Color/material |
White/Metal
|
| Dimension (WXHXD) |
Ø135x126.5mm
|
| Weight |
Appr. 846g
|
|
| Focal Length (Zoom Ratio) |
2.8-12mm
|
| Max. Aperture Ratio |
F No. 1.2
|
| Angular Field Of View |
113(W)-35(T)° V
|
| Min. Object Distance |
1.5m
|
| Lens Type |
Motorized Ø16.7
|
|
| Imaging Device |
1/2.7”
|
| Effective Pixels |
5MP 2880 (H) x 1620 (V)
|
| Scanning System |
Progressive CMOS
|
| Min. Illumination |
Color 0.002lux @ F1.0(AGC ON) ; B/W 0 lux @ IR ON
|
|
MICRO SD CARD SLOT UP TO 256 GB
