PRODUCT SPECIFICATIONS
OPERATIONAL | |
IR LED | 1 |
Warmlight | 2 |
Red & Blue Light | 2 (1 Red & 1 Blue) |
IR Viewable Length | Up to 25m |
Warmlight Viewable Length | Up to 20m |
Type Of Complementary Light | Default warm light, switchable infrared light |
Wide Dynamic Range | DWDR |
Digital Noise Reduction | 3D DNR |
Motion Detection | Off/On (8 Levels) |
Image Setting | Full Color Mode/Day&Night Mode/Smart IIIumination |
White Balance | Auto/Manual |
Electronic Shutter Speed | 1/5 ~ 1/20000s |
On-Board Storage | Micro SD slot, up to 256GB |
Alarm | Speaker, siren |
Audio | Built-in microphone & speaker |
Hardware Reset | Yes |
Smart Features | Perimeter Intrusion Detection (PID), Line Crossing Detection (LCD), Intrusion Detection (ID), Region Entry and Exiting |
NETWORK | |
Ethernet | RJ45(10/100BASE-T) |
Video Compression Format | H.265/H.264 |
Resolution | 4MP(2560x1440) Sub Stream@25fps |
Video Quality Adjustment | 512Kbps ~ 4Mbps |
Bitrate Control Method | CBR/VBR |
IP | IPv4 |
Protocol | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,SMTP,NTP,HTTPS |
Security | Complicated password; Authenticated username and password |
Application Programming Interface | ONVIF( Profil S/G/T) |
Compatible Web Browsers | IE10/11 |
GENERAL | |
Operating Conditions | -35°+60°C/ Less than ≤ 95% RH |
Ingress Protection | IP67 |
Input Voltage / Current | D12V/POE (IEEE802.3af) |
Power Consumption | max 7.5W |
Color/material | White/Metal |
Dimensions (LXHXP) | 100*100*90mm |
Weight | 320g |
LENS | |
Focal Length (Zoom Ratio) | 2.8 mm |
Max. Aperture Ratio | F No. 1.0 |
Angular Field Of View | 95°, Vertical |
Min. Object Distance | 2m |
Lens Type | Fixed (M12) |
VIDEO | |
Imaging Device | 1/3” |
Effective Pixels | 4MP 2560(H)×1440 (V) |
Scanning System | Progressive CMOS |
Min. Illumination | Color 0.002 Lux @ (F1.0, AGC ON) ; B/W 0 lux @ IR ON |
COLOR | |
Color | BLACK , WHITE |
