PRODUCT SPECIFICATIONS
OPERATIONAL | |
IR LED | 1 |
Warmlight | 2 |
Red & Blue Light | 2 (1 Red & 1 Blue) |
IR Viewable Length | Up to 25m |
Warmlight Viewable Length | Up to 20m |
Type Of Complementary Light | Default warm light, switchable infrared light |
Wide Dynamic Range | WDR |
Digital Noise Reduction | 3D DNR |
Motion Detection | Off/On (8 Levels) |
Image Setting | Day&Night Mode/Full Color Mode/Schedule |
White Balance | Auto/Manual |
Electronic Shutter Speed | 1/5 ~ 1/20000s |
On-Board Storage | Micro SD slot, up to 256GB |
Alarm | N/A |
Audio | Built-in microphone & speaker |
Custom Voice | Yes |
Hardware Reset | Yes |
Smart Features | Rare Sound Detection (SD) , Perimeter Intrusion Detection (PID), Face Detection (FD), Stationary Object Detection (SOD), Crowd Density Detection (CD), Human&Vehicle Detection (PD&VD), Line Crossing Detection (LCD), Queue Lenght Detection (QD), Heat Map (HM), Cross Counting (CC), License Plate Detection (LPD) |
NETWORK | |
Ethernet | RJ45(10/100BASE-T) |
Video Compression Format | H.265/H.264 |
Resolution | Mainstream @30fps 8MP(3840x2160), 5MP(2592x1944) (3072x1728), 4MP(2592x1520), 3MP(2304x1296), 1080P(1920x1080), 960P(1280x960),720P(1280x720) Substream @30fps 720P(1280x720), VGA(640x480), QVGA(320x240) Mobile Stream @30fps VGA (640x480), QVGA (320x240) |
Video Quality Adjustment | 256Kbps ~ 16Mbps |
Bitrate Control Method | CBR/VBR |
IP | IPv6 |
Protocol | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP |
Security | IP address filter;complicated password; Authenticated username and password |
Application Programming Interface | ONVIF( Profile S/G/T) |
Compatible Web Browsers | IE10/11, Safari V12.1/above, Firefox V.52/above, Google chrome V.57/above, Edge V.79/above |
GENERAL | |
Operating Conditions | -35°+60°C/ Less than ≤ 95% RH |
Ingress Protection | IP67 |
Input Voltage / Current | D12V/POE (IEEE802.3af) |
Power Consumption | Max. 6.6W |
Color/material | White/Metal |
Dimensions (LXHXP) | 100*100*90mm |
Weight | 425g |
LENS | |
Focal Length (Zoom Ratio) | 2.8 mm |
Max. Aperture Ratio | F No. 1.0 |
Angular Field Of View | 106°, Vertical |
Min. Object Distance | 2m |
Lens Type | Fixed (M12) |
VIDEO | |
Imaging Device | 1/2.7” |
Effective Pixels | 8MP 3840(H)×2160(V) |
Scanning System | Progressive CMOS |
Min. Illumination | Color 0.007lux @ F1.0(AGC ON) ; B/W 0 lux @ IR ON |
COLOR | |
Color | BLACK , WHITE |
