PRODUCT SPECIFICATIONS
OPERATIONAL | |
IR Viewable Length | Up to 30m |
Camera Title | On/Off |
Day & Night | IR cut filter with auto switch (Day/Night/Auto/Image/Schedule) |
Backlight Compensation | Off/On (5 Zones) |
Wide Dynamic Range | DWDR |
Digital Noise Reduction | 3D DNR |
Motion Detection | Off/On (8 Levels) |
Privacy Masking | Off/On (4 Zones, Rectangle) |
Gain Control | Auto |
White Balance | Auto/Manual |
Electronic Shutter Speed | 1/5 ~ 1/20000s |
On-Board Storage | Micro SD slot, up to 256GB |
Alarm | NA |
Audio | Built-in microphone |
Hardware Reset | Yes |
AI Features | Face Recognition, Pedestrian & Vehicle , Perimeter Intrusion , Line Crossing , Object Detection, Crossing Counting, Heat Map, Crowd Density , Queue Length , License Plate, Rare Sound, Intrusion, Region Entrance, Region Exiting |
NETWORK | |
Ethernet | RJ45(10/100BASE-T) |
Video Compression Format | H.265/H.264 |
Resolution | 12MP (4096x3072)@15fps, 8MP (3840x2160)@25fps, 5MP (2592x1944,3072x1728)@25fps, 4MP (2592x1520)@25fps, 3MP (2304x1296)@25fps, 1080P (1920x1080)@25fps Sub stream |
Video Quality Adjustment | 256Kbps ~ 16Mbps |
Bitrate Control Method | CBR/VBR |
Streaming Capability | Triple-Stream(Main/Sub/Mobile) |
Protocol | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,SMTP,NTP,UPnP,SNMP,HTTPS,FTP |
Security | IP address filter;complicated password; Authenticated username and password |
Streaming Method | Unicast/Multicast |
Application Programming Interface | ONVIF( Profile S/G/T/M) |
GENERAL | |
Operating Conditions | -35°~+60°C/less than ≤ 90% RH |
Waterproof | IP67 |
Input Voltage / Current | D12V/POE(IEEE802.3af) |
Material | Metal |
Dimensions | Ø100x90mm |
Weight | appr 420g |
LENS | |
Focal Length (Zoom Ratio) | 3.6 mm |
Max. Aperture Ratio | F No. 1.6 |
Angular Field Of View | 87°, Vertical |
Min. Object Distance | 2m |
Lens Type | Fixed (M12) |
VIDEO | |
Imaging Device | 1/2.3” |
Effective Pixels | 12MP 4096(H)×3072(V) |
Scanning System | Progressive CMOS |
Min. Illumination | Color 0.01lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON |
