P2P CONNECTION
PRODUCT SPECIFICATIONS
| GENERAL | |
| Weight | 380g |
| Dimension (WXHXD) | 173*100*30mm |
| Operating Temperature/Humidity | -10°C~+50°C; Humidity |
| Power Supply | 48V/ 1.5A |
| Lightning Protection | 4KV |
| PRODUCT SPECIFICATIONS | |
| Interfaces | 8x10/100M POE+1x100/1000M Gigabit Ethernet |
| Network Management | Lite Manager (CMS connection ,POE power consumer statistics, parameter configuration, log checking, firmware update, network topology) |
| IEEE Standard | 802.3\802.3x\802.3ah\802.3az |
| Uplink Rate (Individual Port) | 1000M |
| Downlink Rate (Individual Port) | 1000M |
| Exchange Capacity | 3.6Gbps |
| Packet Forwarding Rate | 2.6Mpps |
| Internal Cache | 4Mbits |
| POE Standard | IEEE 802.3at/af |
| POE Port | 1-8 |
| Extension Mode (EPOE) | 250 Meters |
| Max. Power (Individual Port) | 30W |
| Max. Power (All Ports) | 65W |
| Case | Metal |
| Storage Temperature/Humidity | -40°C~+85°C; Humidity |
