| Weight |
2861g
|
| Dimension (WXHXD) |
440*221*44mm
|
| Operating Temperature/Humidity |
-10°C~+50°C; Humidity
|
| Power Supply |
100~240VAC 50/60Hz Max4A 52V/4.8A 250W
|
| Lightning Protection |
4KV
|
|
| Interfaces |
16x10/100M POE+2x100/1000M Gigabit Ethernet
|
| Network Management |
Lite Manager (CMS connection ,POE power consumer statistics, parameter configuration, log checking, firmware update, network topology)
|
| IEEE Standard |
IEEE 802.3\802.3u\802.3ab\802.3x\ 802.3z\802.3af\802.3at
|
| Uplink Rate (Individual Port) |
1000M
|
| Downlink Rate (Individual Port) |
1000M
|
| Exchange Capacity |
7.2Gbps
|
| Packet Forwarding Rate |
5.36Mpps
|
| Internal Cache |
2.75Mbits
|
| POE Standard |
IEEE 802.3at/af
|
| POE Port |
1~16
|
| Extension Mode (EPOE) |
250 Meters
|
| Max. Power (Individual Port) |
30W
|
| Max. Power (All Ports) |
230W
|
| Case |
Metal
|
| Storage Temperature/Humidity |
-40°C~+85°C; Humidity
|
|
