BUILT-IN MICROPHONE
Two-Way Audio
You can easily communicate in real-time through the app. Whether you’re speaking or listening, the audio feature allows for seamless, two-way communication, ensuring that both parties can hear and respond instantly.
Alarms
Arm and activate your alarm relays, deterrence lights, and sirens instantly through the Smart Guardian app. With just a few taps, you can ensure your property is fully secured, deterring potential intruders and triggering an immediate response.
Discover moreRemote Setup
With remote setup, you can complete your entire system configuration directly through the app, eliminating the need for connecting to a separate monitor or physical device. Our app gives you full control, ensuring a smooth, hassle-free setup experience without any extra equipment.
Learn more
Instant Notifications
Receive real-time alerts for various events, including alarm triggers, human and vehicle detections, movement, face recognition matches, hard disk errors, and video loss. Tailor your notifications to ensure you’re always updated on what’s happening.
Discover morePRODUCT SPECIFICATIONS
| NETWORK | |
| Security | Password protection, IP address filtering, Di- gest authentication, User access log, firewall |
| VOIP | OPUS, MP3, G.722, PCMU, PCMA |
| Amplifier Description | Built-in 30W Amplifier |
| GENERAL | |
| Power Supply | PoE.at , PoE.at or DC 12V/24V |
| Material | ABS , ABS (IP66 water-resistant) |
| Weight | 2.30 Kg Gross |
| Operating Temperature | ’-30°C — +60°C |
| Storage Temperature | ’-40°C — +70°C |
| Operating Humility | 5%-85% |
| Rate Power | 30W |
| Connector | Alarm in, Audio in, DC Power, PoE, TF Card (Optional) |
| Installation | Wall Mounted |
| Dimensions | 285*205*290mm |
| Net Weight | 2 KG |
| Languages | English |
| VIDEO & AUDIO | |
| Network Interface | 10/100Base-TX, RJ45 , 10/100 Base-TX, RJ45 |
| INTERFACE | |
| Built-In Microphone | Yes |
| AUDIO | |
| Audio Support Codec | OPUS 48 kHz, MP3 44.1 kHz, G.722 ADPCM 16 kHz, G.711 PCMU 8 kHz, G.711 PCMA 8 kHz |
| Max SPL | 120dB |
| Frequency Range | 500-2KHZ +-10dB 400-12KHZ +-20dB |
| Harmonic Distortion | 0.1@1kHz |
| Signal To Noise Ratio | 91dB |
| Coverage Pattern | 60°horizontal 90°vertical (at 2kHz) |
| CONNECTIONS | |
| Rated Power | 30W |
| Audio Decoding | MP3, WMA, WAV |
| Speaker Sensitivity | 105dB |
| Coverage Pattern Angle | 60 degrees horizontal 90 degrees vertical at 2kHz |
| Audio Streaming | Full echo cancellation , Full echo cancellation |
| Audio Support | OPUS 48 kHz, MP3 44.1 kHz, G.722 ADPCM 16 kHz, G.711 PCMU 8 kHz, G.711 PCMA 8 kHz |
| Network Security Protocols | HTTPS, TLS v1.2/v1.3, host-based firewall , HTTPS, TLS v1.2/v1.3, host-based firewall |
| Approvals | CE, FCC, Rohs , CE, FCC, Rohs |
| Frequency Response | 350Hz~8KHz , 350Hz~8KHz |
| Product Dimension | 285 x 205x 290 mm |
| Condition Temperatures | -30 ° — +60 °, Storage |
| EXTPOE | |
| Network Protocol | SIP,ONVIF , SIP, ONVIF, HTTP, IPv4, DHCP, RTSP, RTP, RTCP, TCP, UDP, ARP, FTP, TFTP, NFS, NTP , SIP, ONVIF, HTTP, IPv4, DHCP, RTSP, RTP, RTCP, TCP, UDP, ARP, FTP, TFTP, NTP |
