PRODUCT SPECIFICATIONS
| Voltage Type | AC 100V~240V 50Hz/60Hz |
| Standards/Protocols | IEEE 802.3u, IEEE 802.1Q,IEEE 802.1p,IEEE 802.3af/at |
| Productiveness Type | ≥85% |
| Output Voltage | 52V Fully loaded |
| Output Current | 2.88A |
| Rating | 150W |
| POE Power | 35W POE af/at, 90W POE bt |
| Ripple Wave VPP | ≤100mV |
| Overcurrent Protection | Yes |
| Overvoltage Crowbar | Yes |
| Short-Circuit Protection | Yes |
| Wave Surge Protection | Yes |
| Pilot Lamp | Power output indicator light, when the device normal output, red always bright. Green light |
| Short-Circuit Protection | When the output is short circuit to the ground, the built- in chip will close the output. When the short circuit is lifted, the device will automatically return to normal. |
| Ageing Time | All full load aging for 6~8 hours, and with load for surge voltage impact test for 100 times |
| Work Temperature | -40°C~+70°C 20~95%RH No condensation |
| Lay In Temperature | -40°C~+80°C 10~95%RH |
| Temperature Coefficient | ±0.03%°C |
