| AI Features |
HUMAN & VEHICLE DETECTION STATIONARY OBJECT DETECTION LICENSE PLATE DETECTION HEAT MAP CROWD DENSITY DETECTION NOISE DETECTION VIDEO TAMPERING CROSS COUNTING INTRUSION DETECTION REGION ENTRANCE & EXITING QUEUE LENGTH DETECTION AI REGISTERED QUANTITY 10,000 INSTANT NOTIFICATIONS AI MAX CAPTURED QUANTITY 200,000 PERIMETER INTRUSION DETECTION LINE CROSSING DETECTION FACE DETECTION RARE SOUND DETECTION
|
|
| Web |
IE10/11. Safari V12.1 above, Firefox V.52 above Google chrome V.57 above, Edge V.79 above
|
| Ethernet |
2 RJ45 1000 Base-T
|
|
| OSD Language |
EN/FR/ES/DN/TC/IN/JP/KR
|
| Dimension (WXHXD) |
440*460*189mm
|
| Input Voltage / Current |
AC 110~240V ATX 250W
|
| Power Consumption (Excluding Hard Disk) |
30-44WATT
|
| Operating Temperature/Humidity |
0°C~+40°C (32°F ~ 104°F) Humidity
|
|
| Hard Drive PURPLE |
NO PURPLE HDD
,
32TB
,
64TB
,
96TB
,
128TB
,
192TB
|
| Hard Drive GOLD |
NO GOLD HDD
,
64TB-R
,
128TB-R
,
192TB-R
|
|
| Frame Rate |
240fps 4MP
|
|
| P/W Reset |
Press 3 seconds
|
| HDMI |
3 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 2560*1440, 3840*2160/EDID) 1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 /EDID) Async out
|
| Hot Swappable HDD |
Yes
|
|
| Inputs |
8MP,5MP, 3MP ,2MP(1080P),1.3MP(960P),1.0MP(720P)
|
| Input |
1024M
|
| Out |
1024M
|
| RS232 |
1*RJ45
|
|
| Compression |
G.711a Video
|
| Event |
MD (Sensitivity Level 1~8) Videlo loss Beep, Email, Push notification to Mobile APP
|
| Playback |
Fast forward / backward (2x, 4x, 8x,16X) Slow forward (1/2x, 1/4x, 1/8x,1/16x)
|
| Raid Type |
RAID0, RAID1, RAID4, RAID5, RAID6 and RAID10
|
|
| Local |
UI5.0
|
| Mobile Viewer |
SMART GUARDIAN
|
| Push Notifications |
Yes
|
|
| USB |
USB2.0*1(front) USB3.0*2(rear)
|
| Audio Out |
1
|
| E-SATA |
1
|
| HDD |
16 SATA HDD, up to 16TB each HDD
|
| Line-In |
1
|
| RS485 |
1
|
| Alarm Input/Out |
16in /4out
|
|
| Live/Playback Performance |
Max 16CH playback
|
|
RACKMOUNT COMPATIBLE
