8MP RESOLUTION
Two-Way Audio
You can easily communicate in real-time through the app. Whether you’re speaking or listening, the audio feature allows for seamless, two-way communication, ensuring that both parties can hear and respond instantly.
Alarms
Arm and activate your alarm relays, deterrence lights, and sirens instantly through the Smart Guardian app. With just a few taps, you can ensure your property is fully secured, deterring potential intruders and triggering an immediate response.
Discover moreRemote Setup
With remote setup, you can complete your entire system configuration directly through the app, eliminating the need for connecting to a separate monitor or physical device. Our app gives you full control, ensuring a smooth, hassle-free setup experience without any extra equipment.
Learn more
Instant Notifications
Receive real-time alerts for various events, including alarm triggers, human and vehicle detections, movement, face recognition matches, hard disk errors, and video loss. Tailor your notifications to ensure you’re always updated on what’s happening.
Discover morePRODUCT SPECIFICATIONS
| OPERATIONAL | |
| AI Features | PERIMETER INTRUSION DETECTION FACE DETECTION LINE CROSSING DETECTION STATIONARY OBJECT DETECTION* HUMAN & VEHICLE DETECTION CROWD DENSITY DETECTION* LICENSE PLATE DETECTION* RARE SOUND DETECTION* NOISE DETECTION* QUEUE LENGTH DETECTION* VIDEO TAMPERING* AI MAX CAPTURED QUANTITY 200,000 AI REGISTERED QUANTITY 10,000 *THESE AI FEATURES ONLY WORK WITH IP CAMERAS, OR ANALOG CAMERAS WITH 2MP OR MORE |
| Audio | 16 in /1 out |
| NETWORK | |
| Web | IE10/11 Safari V12.1 above / Firefox V.52 above Google chrome V.57 above / Edge V.79 above |
| Ethernet | 1 RJ45 100/1000 Base-T |
| GENERAL | |
| OSD Language | Multiple |
| Dimension (WXHXD) | 378*340*50mm |
| Input Voltage / Current | DC12V/5A |
| Power Consumption (Excluding Hard Disk) | ≤20W |
| Operating Temperature/Humidity | 0°C~+40°C (32°F ~ 104°F) Humidity |
| HARD DRIVES | |
| Hard Drive PURPLE | NO PURPLE HDD , 4TB , 8TB , 16TB |
| INTERFACE | |
| P/W Reset | Press 10 seconds |
| VGA | 1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080) |
| HDMI | 1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 2560*1440, 3840*2160/EDID) |
| RECORDING BANDWIDTH | |
| Inputs | 64~192Mbps Decrease one Analog channel can increase 8Mbps Analog channel and digital channel can be converted |
| Out | 192Mbps |
| Analog-Video-Input | 16CH inputs |
| PERFORMANCE | |
| Installation Wizard | Yes |
| Compression | G.711a / Video |
| Display Resolution | 8MP (15fps) / 5MP (20fps) 4MP/3MP/1080P/720P/960H (30fps) IP |
| Speed | 8MP |
| Event | MD (Sensitivity Level 1~8) Videlo loss Beep, Email, Push notification to Mobile APP |
| Playback Function | Fast forward / backward (2x, 4x, 8x,16X) Slow forward (1/2x, 1/4x, 1/8x,1/16x) |
| Playback | 160fps (Max 16CH playback) 5MP |
| UI/MONITORING | |
| Local | UI5.0 |
| Mobile Viewer | SMART GUARDIAN |
| Push Notifications | Yes |
| Channel | 16 |
| BNC | 1 (704*576) |
| CONNECTIONS | |
| USB | USB2.0*1(front) USB3.0*1(rear) |
| E-SATA | 1 |
| HDD | 2 SATA HDD, up to 16TB each HDD |
| RS485 | 1 |
| Alarm Input/Out | 16 in /1 out |
| LIVE | |
| IP Video Input | 8ch (only IP up to 24ch) |
| Composite Video Input | up to 24ch (Analog video + IP video) |
