| AI Features |
PERIMETER INTRUSION DETECTION FACE DETECTION LINE CROSSING DETECTION STATIONARY OBJECT DETECTION* HUMAN & VEHICLE DETECTION CROWD DENSITY DETECTION* LICENSE PLATE DETECTION* RARE SOUND DETECTION* NOISE DETECTION* QUEUE LENGTH DETECTION* VIDEO TAMPERING* AI MAX CAPTURED QUANTITY 200,000 AI REGISTERED QUANTITY 10,000 *THESE AI FEATURES ONLY WORK WITH IP CAMERAS, OR ANALOG CAMERAS WITH 2MP OR MORE
|
| Audio |
4 in / 1 out
|
|
| Web |
IE10/11 Safari V12.1 above Firefox V.52 above Google chrome V.57 above Edge V.79 above
|
| Ethernet |
1 RJ45 10/100 Base-T
|
|
| OSD Language |
EN/FR/ES/DN/TC/IN/JP/KR
|
| Dimension (WXHXD) |
300X227X53mm
|
| Input Voltage / Current |
DC12V/2A
|
| Power Consumption (Excluding Hard Disk) |
4.7W
|
| Operating Temperature/Humidity |
0°C~+40°C (32°F ~ 104°F) Humidity
|
|
| Hard Drive PURPLE |
NO PURPLE HDD
,
1TB
,
2TB
,
4TB
|
|
| P/W Reset |
Press 10 seconds
|
| VGA |
1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080)
|
| HDMI |
1(1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 2560*1440, 3840*2160/EDID)
|
|
| Inputs |
12 Mbps-36Mbps IP Bandwidth default is 12Mbps, decrease one Analog channel can increase 6Mbps Total decoding performance 4K 30fps
|
| Out |
48Mbps
|
| Analog-Video-Input |
4CH Inputs
|
|
| Installation Wizard |
Yes
|
| Compression |
G.711a Video
|
| Display Resolution |
8MP (15fps) 5MP (20fps) 4MP/1080P/720P/960H (30fps) IP
|
| Speed |
8MP
|
| Event |
MD (Sensitivity Level 1~8) Videlo loss Beep, Email, Push notification to Mobile APP
|
| Playback Function |
Fast forward / backward (2x, 4x, 8x,16X) Slow forward (1/2x, 1/4x, 1/8x,1/16x)
|
| Playback |
28fps 5MP
|
|
| Local |
UI5.0
|
| Mobile Viewer |
SMART GUARDIAN
|
| Push Notifications |
Yes
|
| BNC |
1 (704*576)
|
|
| USB |
USB2.0*1 (front) USB2.0*1+(rear)
|
| E-SATA |
1 optional, not supported by default
|
| HDD |
The recorder can support up to 16TB
|
| RS485 |
1
|
| Alarm Input/Out |
4 in /1 out
|
|
| IP Video Input |
2ch,(only IP up to 6ch)
|
| Composite Video Input |
Up to 6ch (Analog video + IP video)
|
|
