BANDWIDTH UP TO 100MBPS
PRODUCT SPECIFICATIONS
| GENERAL | |
| Dimensions(mm) | 76(W) x 55(H) x 24(D) , 76(W) x 55(H) x 24(D) |
| IPCOAX-300M-R | |
| Power Input | PoE (Power over Ethernet) from SC-IPIR07PU , DC 48V~56V Adapter or PoE |
| Power Output | Midspan PoE |
| Max. Transmission Distance | 500m(100Mbps), 800m(10Mbps) , 500m(100Mbps), 800m(10Mbps) |
| Temperature/Humidity | -10°C ~ +50°C / 0 ~ 80% , -10°C ~ +50°C / 0 ~ 80% |
| Connection Port | RJ-45 X 2 , RJ-45 X 2 |
| Case Body/Weight | ABS / 52g , ABS / 54g |
| EXTPOE-1K-R | |
| Max. Digital Transmission Bandwidth | 100Mbps (Bandwidth Switch , 100Mbps (Bandwidth Switch |
| Max. Self-Power Consumption | 2W , 2W |
| Max. Power(POE) Supply | 30W , 30W |
| MAX. TRANSMISSION DISTANCE | |
| 100Mbps | 500m |
| 10Mbps | 800m |
| Video Recorders | |
| POE Ports | 1 |
DOWNLOAD
| DATA SHEET | |
| EN_DATASHEET_EXTPOE-1K_2024-11-08.pdf | Download |
