PRODUCT SPECIFICATIONS
| NETWORK | |
| Network Protocol | 10BASE-T IEEE 802.3u |
| GENERAL | |
| Power Supply | DC48 ~ DC57V |
| Environment | -10 to 70°C; Operating temperature |
| Dimensions | 93 x 105 x 28mm |
| PRODUCT SPECIFICATIONS | |
| POE Standard | IEEE802.3af (POWER-IN, 25.5W) IEEE802.3af (POWER-OUT, 15.4W-MAX) |
| NETWORK PORT PARAMETER | |
| Transmission Distance | 100M |
| EXTPOE | |
| Port Description | 1 RJ45 PORT PoE OUTPUT |
| Network Medium | CAT5 AND ABOVE UTP CABELS (≤120M) |
| Repeater Mode | STORE AND FORWARD |
| Mac Address Table | 1K |
| POE Port Power | 60 WATTS FOR 1 PORT 90 WATTS FOR 4 PORTS |
| LED Display | POE WORKING STATUS, ETHERNET |
| POE Power Supply Type | END-SPAN |
| PoE Cable Core | 1/2 + , 3/6 - |
| Electromagnetic Radiation | FCC CLASS A, CE |
| Video Recorders | |
| POE Ports | 4 |
| Bandwidth | 10/100/1000MBPS |
