| IP Rating |
IP66
|
| Filter |
Removable IR Cut Filter
|
| Pixels |
2688(H)×1944(V)
|
| Horizontal Resolution |
2MP
|
| IR Range |
20 Meters
|
| Electronic Shutter |
1/30-1/100,000s PAL
|
|
| Image Setting |
Contrast, Brightness, Sharpness, Saturation , WDR, 3DNR, HLC,BLC
|
|
| Video Compression |
H.264 / H.265
|
| Audio Compression |
G711A, G711U
|
| Protocol |
TCP/IP, UDP, SMTP, PPPoE, DDNS, DHCP, FTP, RTSP, HTTP, IPv6
|
| Network Support |
ONVIF, API
|
| Web Language |
English, Simplified Chinese, Traditional Chinese
|
|
| Power Supply |
DC12V±10%, POE
|
| Current Consumption |
770mA (Max)
|
| Dimensions |
114x81.8mm (4.49”x3.22”)
|
| Weight |
600g
|
| Storage Temperature |
-30° ~ +60°
|
| Operating Temperature |
-30° ~ +45°
|
|
| Image Sensor |
1/2.8” 5Mega-pixel Sony CMOS
|
|
| Lens |
2.8mm Fixed
|
|
| Transmission Stream Rate |
36Kb~16M)
|
| Frame Rate |
1~25fps (PAL) ,1~30fps (NTSC)
|
| Network Interface |
RJ45*1 10M/100M
|
| Remote Control Interface |
/
|
| Audio Interface |
input/output*1
|
| Alarm Interface |
input/output*1
|
|
| Users |
10
|
| Storage |
NVR, VMS, TF Card
|
| Video Type |
Manual, Timing, Motion Detection, Face Detection
|
| Alarm Triggers |
Motion Detection, AI Face Detection
|
| Alarm Event |
Snapshot, Video, Alarm Output, Email Upload,
|
| System/Explorer Support |
IE, Chrome, Firefox, Safari
|
| General Function |
Flashing, Mirror, OSD information overlay, Camera angle, Banner
|
|
| Min. Illumination |
0 Lux When IR ON
|
|
2.8MM Lens
