PRODUCT SPECIFICATIONS
OPERATIONAL | |
IR Viewable Length | Up to 80m |
Camera Title | Show/Hide |
Day & Night | IR cut filter with auto switch (Day/Night/Auto/Schedule) |
Backlight Compensation | Off/On (5 Zones) |
Wide Dynamic Range | 120dB |
Digital Noise Reduction | 3D DNR |
Motion Detection | Off/On (8 Levels) |
Privacy Masking | Off/On (4 Zones, Rectangle) |
Gain Control | Auto |
White Balance | Auto/Manual |
Electronic Shutter Speed | 1/5 ~ 1/20000s |
Alarm | 1 input, 1 output |
Audio | 1 input (RCA), 1 output (RCA) |
Hardware Reset | Yes |
Smart Features | Perimeter Intrusion Detection (PID), Face Detection (FD), Stationary Object Detection (SOD), Crowd Density Detection (CD), Human&Vehicle Detection (PD&VD), Line Crossing Detection (LCD), Queue Lenght Detection (QD), Heat Map (HM), Cross Counting (CC) |
On-Board Storage | Micro SD slot, up to 256Go |
NETWORK | |
Ethernet | RJ45(10/100BASE-T) |
Video Compression Format | H.265/H.264 |
Resolution | Mainstream @30fps 8MP(3840x2160),5MP(2592x1944,3072x1728), 4MP(2592x1520),3MP(2304x1296),1080P(1920x1080), 960P(1280*960),720P(1280x720) Substream @30fps 1080P(1920x1080), 720P(1280x720), VGA(640x480) Mobilestream @30fps VGA(640x480), QVGA(320x240) |
Video Quality Adjustment | 256Kbps ~ 16Mbps |
Bitrate Control Method | CBR/VBR |
Streaming Capability | Triple-Stream(Main/Sub/Mobile) |
Protocol | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE, SMTP,NTP,UPnP,SNMP,HTTPS,FTP, |
Security | IP address filter;complicated password; Authenticated username and password |
Streaming Method | Unicast/Multicast |
Application Programming Interface | ONVIF( Profile S/G/T) |
Compatible Web Browsers | IE10/11, Safari V12.1 above, Firefox V.52 above Google chrome V.57 above, Edge V.79 above |
GENERAL | |
Operating Conditions | -35~+60°C/less than ≤ 95% RH |
Ingress Protection | IP67 |
Input Voltage / Current | D12V/POE(IEEE802.3af) |
Power Consumption (IR OFF) | 4W-5W |
Power consumption (IR ON) | 8.5W-10W |
Dimensions (HXWXD) | Ø90 X 301.11mm |
Material | White/Metal |
Weight | appr. 1427g |
LENS | |
Focal Length (Zoom Ratio) | 5.0 - 50 mm |
Max. Aperture Ratio | F 2.0 ±5% |
Angular Field Of View | 7-49°, Vertical |
Lens Type | Motorized(Ø14) |
VIDEO | |
Imaging Device | 1/2.8" |
Effective Pixels | 8MP 3840(H)×2160(V) |
Scanning System | Progressive CMOS |
Min. Illumination | Color 0.009lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON |
