On Demand
5MP Resolution
PRODUCT SPECIFICATIONS
| Effective Pixels | 5MP 2592(H)×1944(V) |
| Main Stream | 5MP (2592*1944) |
| Sub-Stream | 704*576 |
| Frame Rate | 30fps(2560*1440) |
| Image Sensor | 1/2.8” Sony 335 CMOS Sensor |
| DSP | Dual core 32-bit DSP |
| Min. Illumination | Color 0.001Lux@F1.2, B/W 0.0001 Lux@F1.2 |
| Adjust Parameters | WDR,BLC,DNR,AE,AGC,D&N,Mirror,Flip,etc. |
| Underwater Protection | Anti-salt spray, Up to 20m underwater |
| Video Compression | H.264 / H.265 |
| Streaming Capability | Supports dual stream, AVI format |
| Video Bit Rate | Supports 0.1M ~4Mbps bit rate adjustable |
| Frame Rate | Support 1~30fps adjust |
| Alarm Triggers | Motion Detection, Video Blind, Video Loss, Masking |
| Compatible Web Browsers | IE8,9,10,11, Chrome 44/lower, Firefox 51/lower, Safari 11/lower |
| Smart Phone | NA |
| CMS Software | Uniform CMS Software (multiple devices management system) |
| Network Interface | RJ45*1 10M/100M |
| ONVIF | YES |
| POE | Yes |
| Languages | English |
| IR Cut Filter | Set of double light switch IR-CUT filter |
| Lens | 2.8mm Fixed |
| Infrared LED | 4pcs IR Leds |
| IR Distance | 30M |
| Housing Material | 304 stainless steel |
| Connection Port | 1*DC Connector ,1* RJ45(10/100Mpps T) |
| Input Voltage / Current | DC12V/PoE(802.3af/820.3at) |
| Power Consumption | 600mA max., IR Off |
| Working Temperature | -40°C~+60°C, 10%~90% |
| Dimensions (L*W*H) | 255mm*140mm*110mm |
| Weight | 3.3Kg |
| IP Rating | IP68 |
| Protection Rating | IK10 |
