| IR LED |
1
|
| Warmlight |
2
|
| Red & Blue Light |
2 (1 Red & 1 Blue)
|
| IR Viewable Length |
Up to 25m
|
| Warmlight Viewable Length |
Up to 20m
|
| Type Of Complementary Light |
Default warm light, switchable infrared light
|
| Wide Dynamic Range |
DWDR
|
| Digital Noise Reduction |
3D DNR
|
| Motion Detection |
Off/On (8 Levels)
|
| Image Setting |
Full Color Mode/Day&Night Mode/Smart IIIumination
|
| White Balance |
Auto/Manual
|
| Electronic Shutter Speed |
1/5 ~ 1/20000s
|
| On-Board Storage |
Micro SD slot, up to 256GB
|
| Alarm |
Speaker, siren
|
| Audio |
Built-in microphone & speaker
|
| Hardware Reset |
Yes
|
| Smart Features |
Perimeter Intrusion Detection (PID), Line Crossing Detection (LCD), Intrusion Detection (ID), Region Entry and Exiting
|
|
| Ethernet |
RJ45(10/100BASE-T)
|
| Video Compression Format |
H.265/H.264
|
| Resolution |
4MP(2560x1440) Sub Stream@25fps
|
| Video Quality Adjustment |
512Kbps ~ 4Mbps
|
| Bitrate Control Method |
CBR/VBR
|
| IP |
IPv4
|
| Protocol |
TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,SMTP,NTP,HTTPS
|
| Security |
Complicated password; Authenticated username and password
|
| Application Programming Interface |
ONVIF( Profil S/G/T)
|
| Compatible Web Browsers |
IE10/11
|
|
| Operating Conditions |
-35°+60°C/ Less than ≤ 95% RH
|
| Ingress Protection |
IP67
|
| Input Voltage / Current |
D12V/POE (IEEE802.3af)
|
| Power Consumption |
max 7.5W
|
| Color/material |
White/Metal
|
| Dimensions (LXHXP) |
100*100*90mm
|
| Weight |
320g
|
|
| Focal Length (Zoom Ratio) |
2.8 mm
|
| Max. Aperture Ratio |
F No. 1.0
|
| Angular Field Of View |
95°, Vertical
|
| Min. Object Distance |
2m
|
| Lens Type |
Fixed (M12)
|
|
| Imaging Device |
1/3”
|
| Effective Pixels |
4MP 2560(H)×1440 (V)
|
| Scanning System |
Progressive CMOS
|
| Min. Illumination |
Color 0.002 Lux @ (F1.0, AGC ON) ; B/W 0 lux @ IR ON
|
|
| Color |
WHITE
,
BLACK
|
|
SEE IN COLOR AT NIGHT
