| IR Viewable Length |
Up to 30m
|
| Camera Title |
Show/Hide
|
| Day & Night |
IR cut filter with auto switch (Day/Night/Auto/Image/Schedule)
|
| Backlight Compensation |
Off/On (5 Zones)
|
| Wide Dynamic Range |
WDR
|
| Digital Noise Reduction |
3D DNR
|
| Motion Detection |
Off/On (8 Levels)
|
| Privacy Masking |
Off/On (4 Zones, Rectangle)
|
| Gain Control |
Auto
|
| White Balance |
Auto/Manual
|
| Electronic Shutter Speed |
1/5 ~ 1/20000s
|
| On-Board Storage |
Micro SD slot, up to 256GB
|
| Alarm |
NA
|
| Audio |
Built-in microphone
|
| Hardware Reset |
Yes
|
| Smart Features |
Rare Sound Detection (SD) , Perimeter Intrusion Detection (PID), Face Detection (FD), Stationary Object Detection (SOD), Crowd Density Detection (CD), Human&Vehicle Detection (PD&VD), Line Crossing Detection (LCD), Queue Lenght Detection (QD), Heat Map (HM), Cross Counting (CC), License Plate Detection (LPD)
|
|
| Ethernet |
RJ45(10/100BASE-T)
|
| Video Compression Format |
H.265/H.264
|
| Resolution |
Mainstream@30fps 8MP(3840x2160), 5MP(2592x1944) (3072x1728), 4MP(2592x1520), 3MP(2304x1296), 1080P(1920x1080), 960P(1280x960), 720P(1280x720) Substeam@30fps 1080P(1920x1080), 720P(1280x720), VGA(640x480) Mobilestream@30fps VGA(640x480), QVGA (320x240)
|
| Video Quality Adjustment |
256Kbps ~ 16Mbps
|
| Bitrate Control Method |
CBR/VBR
|
| Streaming Capability |
Triple-Stream(Main/Sub/Mobile)
|
| Protocol |
TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
|
| Security |
IP address filter;complicated password; Authenticated username and password
|
| Streaming Method |
Unicast/Multicast
|
| Application Programming Interface |
ONVIF( Profile S/G/T)
|
| Compatible Web Browsers |
IE10/11, Chrome V.57/above, Firefox V.52/above, Safari V.12.1/above, Edge V.79/above
|
|
| Operating Conditions |
-35°+60°C/less than ≤ 95% RH
|
| Ingress Protection |
IP67
|
| Input Voltage / Current |
D12V/POE(IEEE802.3af)
|
| Power Consumption (IR OFF) |
3W-4W
|
| Power consumption (IR ON) |
5W-6.5W
|
| Color/material |
White/Metal
|
| Dimension (WXHXD) |
Ø100x90mm
|
| Weight |
appr. 420g
|
|
| Focal Length (Zoom Ratio) |
2.8 mm
|
| Max. Aperture Ratio |
F No. 1.6
|
| Angular Field Of View |
105°, Vertical
|
| Min. Object Distance |
1.8m
|
| Lens Type |
Fixed (M12)
|
|
| Imaging Device |
1/2.8"
|
| Effective Pixels |
8MP 3840(H) × 2160(V)
|
| Scanning System |
Progressive CMOS
|
| Min. Illumination |
Color 0.009lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON
|
|
| Color |
WHITE
,
BLACK
|
|
2.8MM Lens
