Imaging Device
|
1/2.7”
|
|
Effective Pixels
|
5MP 2880(H) × 1620(V)
|
|
Scanning System
|
Progressive CMOS
|
|
Min. Illumination
|
Color 0.004lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON
|
|
Focal Length (Zoom Ratio)
|
2.8-12mm
|
|
Max. Aperture Ratio
|
F No. 1.8 (W) ~ 3.3(T)
|
|
Angular Field Of View
|
34 ~107°, Vertical
|
|
Min. Object Distance
|
0.2M~INF
|
|
Lens Type
|
Motorized (Ø14)
|
|
IR Viewable Length
|
Up to 45m
|
|
Camera Title
|
Show/Hide
|
|
Day & Night
|
IR cut filter with auto switch (Day/Night/Auto/Image/Schedule)
|
|
Backlight Compensation
|
Off/On (5 Zones)
|
|
Wide Dynamic Range
|
WDR
|
|
Digital Noise Reduction
|
3D DNR
|
|
Motion Detection
|
Off/On (8 Levels)
|
|
Privacy Masking
|
Off/On (4 Zones, Rectangle)
|
|
Gain Control
|
Auto
|
|
White Balance
|
Auto/Manual
|
|
Electronic Shutter Speed
|
1/5 ~ 1/20000s
|
|
On-Board Storage
|
Micro SD slot, up to 1TB
|
|
Alarm
|
1 input, 1 output
|
|
Audio
|
1 input (RCA), 1 output (RCA)
|
|
Hardware Reset
|
Yes
|
|
Smart Features
|
Perimeter Intrusion Detection (PID), Line Crossing Detection (LCD), Stationary Object Detection (SOD), Human&Vehicle Detection (PD&VD), Face Detection (FD), Cross Counting (CC), Crowd Density Detection (CD), Queue Lenght Detection (QD), Heat Map (HM)
|
|
Ethernet
|
RJ45(10/100BASE-T)
|
|
Video Compression Format
|
H.265/H.264
|
|
Resolution
|
Mainstream@30fps 5MP(2880x1620), 4MP(2560x1440), 3MP(2304x1296), 1080P(1920x1080), 720P(1280x720) Substeam@30fps 720P(1280x720), VGA(640x480), QVGA(320x240) Mobilestream@30fps VGA(640x480), QVGA(320x240)
|
|
Video Quality Adjustment
|
256Kbps ~ 8Mbps
|
|
Bitrate Control Method
|
CBR/VBR
|
|
Streaming Capability
|
Triple-Stream(Main/Sub/Mobile)
|
|
Protocol
|
TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP
|
|
Security
|
IP address filter; complicated password; Authenticated username and password
|
|
Streaming Method
|
Unicast/Multicast
|
|
Application Programming Interface
|
ONVIF( Profile S/G/T)
|
|
Compatible Web Browsers
|
IE10/11, Chrome V.57/above, Firefox V.52/above, Safari V12.1/above, Edge V.79/above
|
|
Operating Conditions
|
-40~+55°C/less than ≤ 95% RH
|
|
Ingress Protection
|
IP67
|
|
Input Voltage / Current
|
D12V/POE(IEEE802.3af)
|
|
Power Consumption (IR OFF)
|
3W/4W
|
|
Color
|
WHITE
,
BLACK
|
|
Power consumption (IR ON)
|
7W/9W
|
|
Color/material
|
Black/Metal
|
|
Dimensions (HXWXD)
|
Ø135.56x127mm
|
|
Weight
|
846g
|
5MP Resolution
