BUILT-IN MICROPHONE
PRODUCT SPECIFICATIONS
| Rated Power | 30W |
| Power Supply | PoE.at |
| Network Protocol | SIP,ONVIF |
| Audio Decoding | MP3, WMA, WAV |
| Network Interface | 10/100Base-TX, RJ45 |
| Speaker Sensitivity | 105dB |
| Coverage Pattern Angle | 60 degrees horizontal 90 degrees vertical at 2kHz |
| Network Protocol | SIP, ONVIF, HTTP, IPv4, DHCP, RTSP, RTP, RTCP, TCP, UDP, ARP, FTP, TFTP, NFS, NTP |
| Audio Streaming | Full echo cancellation |
| Audio Support | OPUS 48 kHz, MP3 44.1 kHz, G.722 ADPCM 16 kHz, G.711 PCMU 8 kHz, G.711 PCMA 8 kHz |
| Network Security Protocols | HTTPS, TLS v1.2/v1.3, host-based firewall |
| Approvals | CE, FCC, Rohs |
| Frequency Response | 350Hz~8KHz |
| Material | ABS |
| Product Dimension | 285 x 205x 290 mm |
| Weight | 2.30 Kg Gross |
| Condition Temperatures | -30 ° — +60 °, Storage |
| Audio Support Codec | OPUS 48 kHz, MP3 44.1 kHz, G.722 ADPCM 16 kHz, G.711 PCMU 8 kHz, G.711 PCMA 8 kHz |
| Built-In Microphone | Yes |
| Max SPL | 120dB |
| Frequency Response | 350Hz~8KHz |
| Frequency Range | 500-2KHZ +-10dB 400-12KHZ +-20dB |
| Harmonic Distortion | 0.1@1kHz |
| Signal To Noise Ratio | 91dB |
| Coverage Pattern | 60°horizontal 90°vertical (at 2kHz) |
| Audio Streaming | Full echo cancellation |
| Security | Password protection, IP address filtering, Di- gest authentication, User access log, firewall |
| Network Protocol | SIP, ONVIF, HTTP, IPv4, DHCP, RTSP, RTP, RTCP, TCP, UDP, ARP, FTP, TFTP, NTP |
| Network Security Protocols | HTTPS, TLS v1.2/v1.3, host-based firewall |
| Network Interface | 10/100 Base-TX, RJ45 |
| VOIP | OPUS, MP3, G.722, PCMU, PCMA |
| Amplifier Description | Built-in 30W Amplifier |
| Operating Temperature | ’-30°C — +60°C |
| Storage Temperature | ’-40°C — +70°C |
| Operating Humility | 5%-85% |
| Material | ABS (IP66 water-resistant) |
| Rate Power | 30W |
| Power Supply | PoE.at or DC 12V/24V |
| Connector | Alarm in, Audio in, DC Power, PoE, TF Card (Optional) |
| Installation | Wall Mounted |
| Dimensions | 285*205*290mm |
| Net Weight | 2 KG |
| Languages | English |
| Approvals | CE, FCC, Rohs |
