5MP Resolution
PRODUCT SPECIFICATIONS
| OPERATIONAL | |
| IR Viewable Length | NA |
| Camera Title | On/Off |
| Backlight Compensation | Off/On (5 Zones) |
| Wide Dynamic Range | WDR |
| Digital Noise Reduction | 3D DNR |
| Motion Detection | Off/On (8 Levels) |
| Privacy Masking | Off/On (4 Zones, Rectangle) |
| Gain Control | Auto |
| White Balance | Auto/Manual |
| Electronic Shutter Speed | 1/5 ~ 1/20000s |
| On-Board Storage | NA |
| Alarm | NA |
| Audio | 1 Input, 1 Output |
| Hardware Reset | Yes |
| AI Features | Face Detection, Pedestrian & Vehicle , Perimeter Intrusion , Line Crossing, Object Detection, Crossing Counting, Heat Map, Crowd Density , Queue Length, License Plate, Rare Sound, Intrusion, Region Entrance, Region Exiting |
| NETWORK | |
| Ethernet | RJ45(10/100BASE-T) |
| Video Compression Format | H.265/H.264 |
| Resolution | Main Stream@30fps 5MP(2880x1620),4MP(2560x1440) 3MP(2304x1296),1080P(1920x1080) 720P(1280x720) Sub Stream@30fps 720P(1280x720),VGA(640x480),QVGA(320x240) Mobile Stream@30fps VGA(640x480), QVGA(320x240) |
| Video Quality Adjustment | 256Kbps ~ 8Mbps |
| Bitrate Control Method | CBR/VBR |
| Streaming Capability | Triple-Stream(Main/Sub/Mobile) |
| Protocol | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,UPnP,SNMP,HTTPS,FTP |
| Security | IP address filter; complicated password; Authenticated username and password |
| Streaming Method | Unicast/Multicast |
| Application Programming Interface | ONVIF( Profile S/G/T) |
| GENERAL | |
| Operating Conditions | -35~+60°C/less than ≤ 90% RH |
| Input Voltage / Current | D12V/POE(IEEE802.3af) |
| Material | Metal |
| INTEGRATION | |
| Web Browser | IE10/11, Safari V12.1 above, Firefox V.52 above Google chrome V.57 above, Edge V.79 above |
| LENS | |
| Focal Length (Zoom Ratio) | 2.0mm |
| Max. Aperture Ratio | F No. 2.8 |
| Angular Field Of View | 96°, Vertical |
| Min. Object Distance | 0.3m~∞ |
| Lens Type | Fixed(M12) |
| VIDEO | |
| Imaging Device | 1/2.7” |
| Effective Pixels | 5MP 2880(H) x1620(V) |
| Scanning System | Progressive CMOS |
| Min. Illumination | Color 0.004lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON |
| COLOR | |
| Color | BLACK |
