New
8MP RESOLUTION
PRODUCT SPECIFICATIONS
| CAMERA | |
| Signal System | PAL/NTSC |
| DNR | SUPPORT |
| AGC | AUTO |
| Doorbell Button | Yes |
| IP Rating | IP65, IK08, NEMA4X |
| OPERATIONAL | |
| White Balance | Auto |
| Video Bit Rate | 8 kbps to 16 Mbps |
| Remote Monitoring | WEB / CMS / APP |
| AI Features | Pedestrian / Face recognitaion |
| NETWORK | |
| BLC | Support |
| Video Compression | H.265+/H.265/H.264+/H.264/MJPEG |
| Audio Compression | G711A/U |
| Online Connection | Supports simultaneous monitoring for up to 10 users. Supports multi-stream real time transmission. |
| Network Protocol | UDP , IPv4, DHCP , NTP , RTSP , DDNS, SMTP , UPnP , HTTPS, HTTP |
| GENERAL | |
| Power Consumption | 9.8W, 12VDC |
| Working Temperature | LESS THAN 95% (NON-CONDENSING) |
| Dimensions | 167mm X 52mm X 39mm |
| Net Weight | 316 g |
| THERMAL MODULE | |
| Aperture | F2.0 |
| Network Cameras | |
| Speaker | VOLUME MAX. 93± 3 dB |
| OPTICAL MODULE | |
| WDR | SUPPORT |
| INTEGRATION | |
| Alarm Input | 1 |
| Alarm Output | 1 |
| VIDEO & AUDIO | |
| Network Interface | IEEE802.3af, 100M PoE |
| FUNCTION | |
| IR Light Distance | 5 METERS |
| Interface Protocol | ONVIF, SIP |
| DTMF | SUPPORT |
| Unlock Methods | CARD/NFC/APP/FACE RECOGNITATIO/ QR CODE |
| Card Type | Mifare Card / Desfire Card/ FM1208 Card |
| Card Reading Frequency | 13.56MHz |
| Users | 3,000 |
| Card Capacity | 30,000 |
| Event Capacity | 150,000 |
| LENS | |
| Focal Length | 1.8MM |
| Angle Of View | 180° V |
| VIDEO | |
| Effective Pixels | 8MP 3840(H)×2160(V) |
| Min. Illumination | 0 LUX WITH IR ON |
| INTERFACE | |
| Wiegand Port | SUPPORT |
| Door contact input | 1 |
| Exit Button | 1 |
| Relay Out (Door Control) | 1 |
| Tamper Alarm | SUPPORT |
| Built-In Microphone | 1 built-in microphone |
| CONNECTIONS | |
| RS485 | SUPPORT |
| Housing Material | Metal Case |
| IPCOAX-300M-R | |
| Power Input | PoE OR DC 12V, 1A |
| RECORDING | |
| TF Card Slot | SUPPORT TF CARD, UP TO 1 TO |
