| AI Features |
Yes
,
HUMAN & VEHICLE DETECTION STATIONARY OBJECT DETECTION LICENSE PLATE DETECTION HEAT MAP CROWD DENSITY DETECTION NOISE DETECTION VIDEO TAMPERING CROSS COUNTING INTRUSION DETECTION REGION ENTRANCE & EXITING QUEUE LENGTH DETECTION AI REGISTERED QUANTITY 10,000 INSTANT NOTIFICATIONS AI MAX CAPTURED QUANTITY 200,000 PERIMETER INTRUSION DETECTION LINE CROSSING DETECTION FACE DETECTION RARE SOUND DETECTION
|
|
| Resolution |
12MP, 8MP, 5MP, 3MP ,2MP(1080P),1.3MP(960P),1.0MP(720P)
|
| Web |
IE10/11, Safari V12.1 above, Firefox V.52 above Google chrome V.57 above, Edge V.79 above
|
| Ethernet |
2 RJ45 100/1000 Base-T
|
|
| OSD Language |
EN/FR/ES/DN/TC/IN/JP/KR
|
| Dimension (WXHXD) |
440*460*89mm
|
| Input Voltage / Current |
ATX 250W
|
| Power Consumption |
12W
|
| Operating Temperature/Humidity |
-10°C~+50°C (14°F ~ 122°F) Humidity
|
|
| Hard Drive PURPLE |
NO PURPLE HDD
,
8TB
,
16TB
,
24TB
,
32TB
|
|
| Frame Rate |
60fps 4MP
|
|
| P/W Reset |
Press 10 seconds
|
| VGA |
1 ( 1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 )
|
| HDMI 1 |
1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080, 2560*1440, 3840*2160/EDID) Sync output with VGA
|
| HDMI 2 |
1 (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080) Async ouptut with HDMI 1
|
|
| Input |
256M
|
| Out |
128M
|
|
| SOC |
NDAA
|
| Installation Wizard |
Yes
|
| Compression |
G.711A;G.711U Video
|
| Event |
MD (Sensitivity Level 1~8) Videlo loss Beep, Email, Push notification to Mobile APP
|
| Playback Function |
Fast forward / backward (2x, 4x, 8x,16X) Slow forward (1/2x, 1/4x, 1/8x,1/16x)
|
| Playback |
Max 16CH playback
|
|
| Local |
UI5.0
|
| Mobile Viewer |
SMART GUARDIAN
|
| Push Notifications |
Yes
|
|
| USB |
USB2.0*1 (front) USB3.0*1+USB2.0*1 (rear)
|
| Audio Out |
1
|
| E-SATA |
1
|
| HDD |
8 SATA , each HDD up to 16TB
|
| Line-In |
1
|
| RS485 |
1
|
| Alarm Input/Out |
16 in /4 out
|
|
ONVIF COMPLIANT (G/M/S/T)
