Two-way communcation
PRODUCT SPECIFICATIONS
| CAMERA | |
| IR Range | Up to 10m |
| OPERATIONAL | |
| Day & Night | IR cut filter with auto switch (Day/Night/Auto/Image/Schedule) |
| Video Bit Rate | 256Kbps ~ 16Mbps |
| Triple Stream | Yes |
| AI Features | N/A |
| NETWORK | |
| Resolution | 4000(H)×3000(V) , Mainstream 4000x3000 1280x960, 640x480 640x480 @15fps Substream Mobilestream 3000x3000 1080x1080, 720x720, 480x480 1080x1080, 720x720, 480x480 1080x1080, 720x720, 480x480 1080x1080, 720x720, 480x480 480x480 @25fps Mainstream Substream Mobilestream 2560x2560 480x480 @25fps Mainstream Substream Mobilestream 2160x2160 480x480 @25fps Mainstream Substream Mobilestream 1520x1520 480x480 @25fps Mainstream Substream Mobilestream 1080x1080 720x720 1080x1080, 720x720, 480x480 1080x1080, 720x720, 480x480 480x480 480x480 @25fps @25fps Mainstream Mainstream Substream Substream Mobilestream Mobilestream |
| Video Compression | H.265/H.264/H.265+/H2.64+/MJPEG |
| BLC | Support |
| ROI | Support |
| Video Analytics | NA |
| Protocols | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/ TSP,PPPoE,SMTP,NTP,UPnP,SNMP,HTTPS,FTP |
| System Compatibility | ONVIF( Profile S, G, T) |
| Interface | RJ45 10M / 100M |
| LED | 3pcs(SMD) |
| SD Storage | Micro SD slot, up to 256GB |
| Alarm Trigger | Yes |
| Video Output | NA |
| Reset Button | Yes |
| GENERAL | |
| POE | Yes |
| Operating Conditions | -35~ +60°C/less than ≤ 95% RH |
| Ingress Protection | IP66 |
| Power Supply | D12V/POE |
| Power Consumption | 3.8-9.6W |
| Dimensions | Ø120*55mm |
| Weight | appr 400g |
| THERMAL MODULE | |
| Image Sensor | 1/2.3” Progressive CMOS |
| Network Cameras | |
| Lens | 2.0mm, horizontal FOV 180° (wall mount), 360°(ceiling mount) |
| MIicrophone | Yes |
| Speaker | Yes |
| OPTICAL MODULE | |
| WDR | DWDR |
| LENS TYPE | |
| F NO. | F 2.0 ±5% |
| VIDEO | |
| Min. Illumination | Color 0.03lux @ F2.0(AGC ON) ; B/W 0 lux @ IR ON |
| Shutter | 1/5 ~ 1/20000s |
