IP67 WATERPROOF DESIGN
PRODUCT SPECIFICATIONS
| NETWORK | |
| Network Protocol | 10BASE-T IEEE 802.3u |
| GENERAL | |
| Power Supply | DC48 ~ DC57V |
| Environment | -10 to 70°C; Operating temperature |
| Dimensions | 31 x 71 x 25mm |
| PRODUCT SPECIFICATIONS | |
| POE Standard | IEEE802.3af (POWER-IN, 13W) IEEE802.3af (POWER-OUT, 13W-MAX) |
| EXTPOE | |
| Port Description | 1 RJ45 PORT PoE OUTPUT |
| Network Medium | CAT5 AND ABOVE UTP CABELS (≤120M) |
| Repeater Mode | STORE AND FORWARD |
| Mac Address Table | 1K |
| POE Port Power | 13 WATTS OUTPUT |
| LED Display | POE WORKING STATUS, ETHERNET |
| POE Power Supply Type | END-SPAN |
| PoE Cable Core | 1/2 + , 3/6 - |
| Electromagnetic Radiation | FCC CLASS A, CE |
| Video Recorders | |
| POE Ports | 1 |
| Bandwidth | 400 MBPS |
