IR UP TO 10M
PRODUCT SPECIFICATIONS
| Imaging Device | 1/2.8” SONY CMOS (IMX323) |
| Effective Pixels | 2.0 Mega Pixels |
| Scanning System | progressive scanning |
| Electronic Shutter Speed | 1/25s~1/50,000s , 1/30s~1/60,000s |
| Min. Illumination (Day) | Color 0.01Lux@F1.2 |
| Min. Illumination (Night) | B/W 0.001 Lux@F1.2 |
| S/N Ratio | More than 50dB (AGC OFF) |
| IR Distance | 10M |
| IR ON/OFF Control | Auto |
| IR LEDS | 18 pieces IR LEDs |
| Lens Type | 3.7mm |
| Mount Type | Pinhole |
| Focal Length | No |
| Max. Aperture | F2.0 |
| Angle Of View | 90° |
| Focus Control | No |
| Resolution | 1920*1080 |
| Frame Rate | 25/30fps |
| Video Output | BNC |
| Day/Night | Yes |
| OSD Menu | Yes |
| BLC Mode | Yes |
| WDR | DWDR |
| Gain Control | AGC |
| Noise Reduction | 3D |
| White Balance | Auto |
| Smart IR | Yes |
| Audio Interface | No |
| Power Supply | DC12V |
| Power Consumption | 600mA max., IR Off |
| Operating Conditions | -10°C ~ +50°C RH95% Max |
| Storage Conditions | 20°C ~ +60°C RH95% Max |
| Ingress Protection & Vandal Resistance | No |
| Material | Plastic |
| Weight | 0.2Kg |
