New
5MP Resolution
PRODUCT SPECIFICATIONS
| CAMERA | |
| Lens Size | 3.7MM |
| IR Distance | 20M |
| OPERATIONAL | |
| Video Bit Rate | Supports 0.1M ~4Mbps bit rate adjustable |
| NETWORK | |
| Main Stream | 5MP (2592*1944) |
| Sub-Stream | 704*576 |
| Video Compression | H.265+/H.265/H.264 |
| Streaming Capability | Supports dual stream, AVI format |
| Audio Compression | G.711 ACC compression |
| GENERAL | |
| ONVIF | YES |
| Languages | English |
| Input Voltage / Current | DC12V/PoE(802.3af/820.3at) |
| Power Consumption | 600mA max., IR Off |
| Environment | -10°C~+60°C, 10%~90% |
| Dimensions | 120*70*46mm |
| Weight | 0.29kg |
| THERMAL MODULE | |
| Image Sensor | 1/2.8” Sony 335 CMOS Sensor |
| INTEGRATION | |
| Web Browser | IE, Chrome, Firefox, Safari |
| VIDEO & AUDIO | |
| Frame Rate | 30fps(2560*1440) , Support 1~30fps adjust |
| Network Interface | RJ45*1 10M/100M |
| FUNCTION | |
| Alarm Triggers | Motion Detection, Video Blind, Video Loss, Masking |
| VIDEO | |
| Effective Pixels | 5MP 2880 (H) x 1620 (V) |
| Min. Illumination | Color 0.001Lux@F1.2, B/W 0.0001 Lux@F1.2 |
| NIGHT VISION | |
| Infrared LED | 48pcs IR Leds(940nm) |
| CONNECTIONS | |
| POE | Yes |
| IPCOAX-300M-R | |
| Connection Port | 1*DC Connector ,1* RJ45(10/100Mpps T) |
| Uncategorized | |
| DSP | Dual core 32-bit DSP |
| Adjust Parameters | WDR,BLC,DNR,AE,AGC,D&N,Mirror,Flip,etc. |
| Smart Phone | Mobile Remote Monitoring (iPhone, Android, Windows Mobile, BlackBerry, Symbian) |
| CMS Software | Uniform CMS Software (multiple devices management system) |
| IR Cut Filter | Set of double light switch IR-CUT filter |
DOWNLOAD
| DATA SHEET | |
| EN_DATASHEET_CVT37IP5MP_2025-08-25.pdf | Download |
